 WETTED HOUSINGS
(Liquid Chambers and Manifolds) | Material | Ship Wt | | Aluminum | 81 kg (177 lbs) | | Ductile Iron | 159 kg (349 lbs) |
NON-WETTED HOUSINGS | Description | Material | | Center Block | Aluminum | | Air Chambers | Aluminum | | Air Valve | Aluminum |
FLOW RATE TO 958 LPM (253 GPM)
MAX PRESSURE = 8.6 BAR (125 PSIG) MAXIMUM SUCTION LIFT CAPABILITY
7.4 m (24.4') dry, 9.0 (29.5') wet MAXIMUM DIAMETER SOLIDS
76 mm (3'') ELASTOMER OPTIONS | Material | Temperature Limits | | Buna-N® | -12.2 (+10) to +82.2 (+180) °C (F°) | | Neoprene | -17.8 (+0) to +93.3 (+200) °C (F°) |
|
