 WETTED HOUSINGS
(Liquid Chambers and Manifolds) | Material | Ship Wt | | Aluminum | 15 kg (34 lbs) | | Ductile Iron | 26 kg (57 lbs) | | Stainless Steel | 28 kg (61 lbs) |
NON-WETTED HOUSINGS | Description | Material | | Center Section | Aluminum | | Air Valve | Aluminum |
FLOW RATE TO 212 LPM (56 GPM)
MAX PRESSURE = 8.6 BAR (125 PSIG) MAXIMUM SUCTION LIFT CAPABILITY
5.5 m (18.2') Dry, 9.0 m (29.5') Wet MAXIMUM DIAMETER SOLIDS
6.4 mm (1/4'') ELASTOMER OPTIONS | Material | Temperature Limits | | Buna-N® | -12.2 (+10) to +82.2 (+180) °C (F°) | | Neoprene | -17.8 (+0) to +93.3 (+200) °C (F°) | | EPDM™ | -51.1 (-60) to +137.8 (+280) °C (F°) | | Polyurethane | -12.2 (+10) to +65.6 (+150) °C (F°) | | Saniflex™ | -28.9 (+20) to +104.4 (+220) °C (F°) | | PTFE | +4.4 (+40) to +104.4 (+220) °C (F°) | | Viton® | -40 (-40) to +176.7 (+350) °C (F°) | | Wil-Flex™ | -40 (-40) to +107.2 (+225) °C (F°) |
|
