 FLOW RATE TO 360 LPM (95 GPM)
MAX INLET AIR PRESSURE = 5.7 BAR (85 PSI)
MAX DISCHARGE PRESSURE 17.2 Bar (250 PSIi) WETTED HOUSINGS
(Water Chambers and Manifolds) | Material | Ship Wt | | 316 Stainless Steel | 128 kg (283 lbs) | | Ductile Iron | 128 kg (283 lbs) |
NON-WETTED HOUSINGS | Description | Material | | Center Block | Aluminum | | Air Valve | Aluminum |
| Temperature Limits | | Operation | 225°F (107°C) | | Cleaning | 225°F (107°C) |
MAXIMUM SUCTION LIFT CAPABILITY
3.7 m (12') Dry 9.0 m (29.5') Wet MAXIMUM DIAMETER SOLIDS
12.7 cm (1/2”) ELASTOMER OPTIONS | Material | Temperature Limits | | PTFE | +4.4 (+40) to +104.4 (+220) °C (F°) | | Wil-Flex™ | -40 (-40) to +107.2 (+225) °C (F°) |
|
