WETTED HOUSINGS(Water Chambers and Manifolds)
MATERIAL SHIP WT.
Polypropylene 75 lbs. (33.8 kg.)
PVDF 95 lbs. (42.9 kg.)
NON-WETTED HOUSINGS
DESCRIPTION MATERIAL
Center Block Polypropylene
Air Chambers Aluminum, Teflon®-coated Aluminum
Air Valve Polypropylene
MAXIMUM SUCTION LIFT CAPABILITY
DRY LIFT 23' (7.0 m)
The above figure represents the rubber-fitted pump capability.
MAXIMUM DIAMETER SOLIDS
1⁄4" (6.35 mm) Diameter
ELASTOMER OPTIONS
MATERIAL TEMPERATURE LIMITS
Polyurethane +10 (–12.2) to +150 ( 65.6) F° (C°)
Neoprene 0 (–17.8) to +200 ( 93.3) F° (C°)
Buna-N® +10 (–12.2) to +180 ( 82.2) F° (C°)
Nordel ® –60 (–51.1) to +280 (137.8) F° (C°)
Viton® –40 (–40.0) to +350 (176.7) F° (C°)
Saniflex™ –20 (–28.9) to +220 (104.4) F° (C°)
Teflon® PTFE +40 ( 4.4) to +220 (104.4) F° (C°)
Wil-Flex™ –40 (–40.0) to +225 (107.2) begin_of_the_skype_highlighting              +225 (107.2)      end_of_the_skype_highlighting F° (C°)
