WETTED HOUSINGS(Water Chambers and Manifolds)
MATERIAL SHIP WT. MATERIAL SHIP WT.
Aluminum 70 lbs. (31.8 kg.) Cast Iron 104 lbs. (47.1 kg.)
316 S.S. 112 lbs. (51.0 kg.) Hastelloy 114 lbs. (51.7 kg.)
NON-WETTED HOUSINGS
DESCRIPTION MATERIAL
Center Block Polypropylene
Air Chambers Aluminum
Air Valve Polypropylene
MAXIMUM SUCTION LIFT CAPABILITY
DRY LIFT 23' (7.0 m)
The above figure represents the rubber-fitted pump capability.
MAXIMUM DIAMETER SOLIDS
1⁄4" (6.35 mm) Diameter
ELASTOMER OPTIONS
MATERIAL TEMPERATURE LIMITS
Polyurethane +10 (–12.2) to +150 ( 65.6) F° (C°)
Neoprene 0 (–17.8) to +200 ( 93.3) F° (C°)
Buna-N® +10 (–12.2) to +180 ( 82.2) F° (C°)
Nordel® –60 (–51.1) to +280 (137.8) F° (C°)
Viton® –40 (–40.0) to +350 (176.7) F° (C°)
Saniflex™ –20 (–28.9) to +220 (104.4) F° (C°)
Teflon® PTFE +40 ( 4.4) to +220 (104.4) F° (C°)
Wil-Flex™ –40 (–40.0) to +225 (107.2) begin_of_the_skype_highlighting              +225 (107.2)      end_of_the_skype_highlighting begin_of_the_skype_highlighting              +225 (107.2)      end_of_the_skype_highlighting begin_of_the_skype_highlighting              +225 (107.2)      end_of_the_skype_highlighting begin_of_the_skype_highlighting              +225 (107.2)      end_of_the_skype_highlighting F° (C°)
